Interior Dimensions:
17.00" x 11.70" x 6.20" (43.2 x 29.7 x 15.7 cm)

Price
$223.95 CAD
Configuration:
No Foam
Color: Black
SKU: IM2300-00000

Free Shipping over $195*

Some exceptions. Details below...

Lifetime Warranty

If it breaks, Pelican will replace it.

30-Day Returns

Return unused items within 30 days.

A Canadian Family Business

Thanks for your support!

Shipping Details

Product Description

The Pelican Storm iM2300 Case

Safely transport your equipment with the Pelican Storm iM2300 Case. Its lightweight yet strong HPX® Resin construction ensures durability, while the smooth exterior makes it easy to clean. With available bezel kits for equipment panels (sold separately) it's a great option for mounting electronics or testing equipment inside. This case is also waterproof, crushproof and dust proof, and features push-button latches for easy access.

Available Accessories for the Pelican Storm iM2300 Case:



iM2300 TrekPak Divider Set
iM2300 Base Bezel Kit for Panel
iM2300 Pick'n'Pluck Foam Set
iM2300 Lid Bezel Kit for Panel

Product Specifications

INTERIOR (L X W X D)
17.00" x 11.70" x 6.20" (43.2 x 29.7 x 15.7 cm)

EXTERIOR (L X W X D)
18.20" x 13.90" x 6.70" (46.2 x 35.3 x 17 cm)

LID DEPTH: 2.00" (5.1 cm)

BOTTOM DEPTH: 4.20" (10.7 cm)

TOTAL DEPTH: 6.2" (15.7 cm)

INT VOLUME: 0.71 ft³ (0.02 m³)

WEIGHT WITH FOAM: 7.10 lbs (3.2 kg)

WEIGHT EMPTY: 5.90 lbs (2.7 kg)

BUOYANCY: 45.64 lbs (20.7 kg)

FOAM LAYERS:

BODY: Injection Molded HPX high performance resin

LATCH: Valox - Polybutylene Terephthalate (PBT)

LATCH (ALT): Xenoy - Polyester/Polycarbonate blend

O-RING: EPDM

PINS: Stainless Steel

PINS (ALT): Aluminum

FOAM: 1.3/1.35 polyester

PURGE BODY: Valox - Polybutylene Terephthalate (PBT)

PURGE BODY (ALT): Xenoy - Polyester/Polycarbonate blend

PURGE VENT: Gortex membrane

MINIMUM TEMPERATURE: -20° F (-29 ° C)

MAXIMUM TEMPERATURE: 140° F (60 ° C)


Add for Total Gear Protection:

Waterproof and Dustproof

MAXIMUM WATER & DUST PROTECTION

A silicone O-ring is fit into a groove in the lid of each Pelican Storm iM2300 Case. This provides the famous IP67 waterproof rating that Pelican cases are known for.

Customizable Cubed Foam Insert

MAXIMUM GEAR PROTECTION

Order this case empty or with a cubed (pick 'n' pluck) foam insert. The foam is scored into cubes so you can create compartments to store and protect your gear. Lay out your gear, mark the foam, and start plucking out the cubes.

Push-Button Latches

HEAVY DUTY. STRONG. DURABLE

The convenient push-button latches found on the Pelican Storm iM2300 Case are sturdy and easy-to-use. The press and pull design ensures the latches cannot be accidentally flipped open during transport.

pelican storm case with push-button latches

Lockable Hasps

LOCK YOUR CASE WITH A PADLOCK

The Pelican Storm iM2300 Case Pelican Storm case has pad-lockable hasps so you can secure your gear in a locked case using a standard combo/keyed padlock or TSA lock.
(Locks not included with case)

Pressure Equalization Valve

KEEP WATER OUT. LET AIR IN.

A woven, waterproof membrane in the valve ensures air molecules pass through while keeping water molecules out.

Your case stays dry and the air pressure inside remains equal to the outside air pressure—preventing a vacuum lock from forming when transporting your Pelican case between altitudes.

The Pelican Storm iM2300 Case

Safely transport your equipment with the Pelican Storm iM2300 Case. Its lightweight yet strong HPX® Resin construction ensures durability, while the smooth exterior makes it easy to clean. With available bezel kits for equipment panels (sold separately) it's a great option for mounting electronics or testing equipment inside. This case is also waterproof, crushproof and dust proof, and features push-button latches for easy access.

Available Accessories for the Pelican Storm iM2300 Case:



iM2300 TrekPak Divider Set
iM2300 Base Bezel Kit for Panel
iM2300 Pick'n'Pluck Foam Set
iM2300 Lid Bezel Kit for Panel

INTERIOR (L X W X D)
17.00" x 11.70" x 6.20" (43.2 x 29.7 x 15.7 cm)

EXTERIOR (L X W X D)
18.20" x 13.90" x 6.70" (46.2 x 35.3 x 17 cm)

LID DEPTH: 2.00" (5.1 cm)

BOTTOM DEPTH: 4.20" (10.7 cm)

TOTAL DEPTH: 6.2" (15.7 cm)

INT VOLUME: 0.71 ft³ (0.02 m³)

WEIGHT WITH FOAM: 7.10 lbs (3.2 kg)

WEIGHT EMPTY: 5.90 lbs (2.7 kg)

BUOYANCY: 45.64 lbs (20.7 kg)

FOAM LAYERS:

BODY: Injection Molded HPX high performance resin

LATCH: Valox - Polybutylene Terephthalate (PBT)

LATCH (ALT): Xenoy - Polyester/Polycarbonate blend

O-RING: EPDM

PINS: Stainless Steel

PINS (ALT): Aluminum

FOAM: 1.3/1.35 polyester

PURGE BODY: Valox - Polybutylene Terephthalate (PBT)

PURGE BODY (ALT): Xenoy - Polyester/Polycarbonate blend

PURGE VENT: Gortex membrane

MINIMUM TEMPERATURE: -20° F (-29 ° C)

MAXIMUM TEMPERATURE: 140° F (60 ° C)

Order your Pelican Storm iM2300 Case from CasePlace Canada
