1690 Transport Case

SKU: 1690-001-110

Interior Dimensions:
30.13" x 25.13" x 15.36" (76.5 x 63.8 x 39 cm)

Price: $735.95 CAD

Configuration:

Color: Black

Quantity

Free Shipping over $195 *

Some Exceptions. Details Below.

30-Day Returns

Return new & unused within 30 days.

Lifetime Warranty

If it breaks, Pelican will replace it.

Shipping Details

Product Description

The 1690 Transport Case:

4 strong polyurethane wheels with stainless steel bearings
Large 2-person fold down handles
Watertight, crushproof, and dustproof
3 level Pick N Pluck with convoluted lid foam
Automatic Pressure Equalization Valve - balances interior pressure, keeps water out
Easy open Double Throw latches
O-ring seal
Open cell core with solid wall design - strong, light weight
Retractable extension handle
Stainless steel padlock protectors
Pelican 1690 Case in Canada at CasePlace.ca

Available Accessories for the 1690 Transport Case:

1690 Lid Organizer

Pelican 1690 Large Case Replacement Foam Sets

Product Specifications

INTERIOR (L X W X D)
30.13" x 25.13" x 15.36" (76.5 x 63.8 x 39 cm)

EXTERIOR (L X W X D)
33.43" x 28.40" x 17.65" (84.9 x 72.1 x 44.8 cm)

LID DEPTH: 2.86" (7.3 cm)

BOTTOM DEPTH: 12.14" (30.8 cm)

TOTAL DEPTH: 15" (38.1 cm)

INT VOLUME: 6.73 ft³ (0.191 m³)

WEIGHT WITH FOAM: 43.00 lbs (19.5 kg)

WEIGHT EMPTY: 34.00 lbs (15.4 kg)

BUOYANCY: 433.00 lbs (196.4 kg)

FOAM LAYERS: Layer 1 (Lid): 3.00" - Convolute / Layer 2 (Base): 1.25" - Pad / Layer 3 (Base): 3.65" - Pick N Pluck / Layer 4 (Base): 3.65" - Pick N Pluck / Layer 5 (Base): 3.65" - Pick N Pluck

BODY: Polypropylene

LATCH: ABS

O-RING: Polymer

PINS: Stainless Steel

FOAM: 1.3 lb Polyurethane

PURGE BODY: ABS

PURGE VENT: 3 Micron Hydrophobic Non-Woven

MINIMUM TEMPERATURE: -40° F (-40 ° C)

MAXIMUM TEMPERATURE: 210° F (99 ° C)

WHEELS: 4

EXTENDABLE HANDLE: yes

1690 Transport Case

Waterproof and Dustproof

MAXIMUM WATER & DUST PROTECTION

A silicone O-ring is fit into a groove in the lid of each Pelican case. This provides the famous IP67 waterproof rating that Pelican cases are known for.

Customizable Cubed Foam Insert

MAXIMUM GEAR PROTECTION

Order your 1690 Transport Case empty or with a removable cubed (pick 'n' pluck) foam insert. The foam is scored into cubes so you can create compartments to store and protect your gear. Lay out your gear, mark the foam, and start plucking out the cubes.

Sturdy Latches

HEAVY DUTY. STRONG. DURABLE

The double-throw latches found on the 1690 Transport Case are durable and provide a positive, sturdy and simple latching system to avoid unwanted opening during transport.

Lockable Hasps

LOCK YOUR CASE WITH A PADLOCK

Secure your gear inside the 1690 Transport Case. There are stainless-steel reinforced hasps beside every latch so you can secure your gear in a locked case using a standard combo/keyed padlock or TSA lock.
(Locks not included with case)

Pressure Equalization Valve

KEEP WATER OUT. LET AIR IN.

A woven, waterproof membrane in the valve ensures air molecules pass through while keeping water molecules out.

Your case stays dry and the air pressure inside remains equal to the outside air pressure—preventing a vacuum lock from forming when transporting your Pelican case between altitudes.

DESCRIPTION SPECIFICATIONS
